Barlows wheel apparatus

(2 customer reviews)

Whatsapp Order

Add to wishlist
Compare

Barlow’s wheel, named after the English mathematician and physicist Peter Barlow, is an early demonstration of electromagnetic induction. It consists of a simple apparatus used to generate electricity by rotating a copper disc between the poles of a magnet. When the disc spins, it cuts across the magnetic field lines, inducing an electric current in the disc due to Faraday’s law of electromagnetic induction.

The apparatus typically consists of a horizontal axle with a copper disc mounted on it, positioned between the poles of a magnet. The copper disc is connected to a circuit, and when it rotates, an electromotive force (emf) is induced in the disc, causing electric current to flow through the circuit.

Barlow’s wheel is a classic demonstration in physics education to illustrate the principles of electromagnetic induction and the generation of electric current. It played a significant role in the development of electrical machinery and the understanding of electromagnetism.

KSh 12,400.00 KSh 13,000.00

Compare

Barlows Wheel Apparatus

  1. Magnet: A magnet, usually in the form of a horseshoe magnet, is positioned such that the poles are close to the copper disc.
  2. Axle: The axle serves as the axis of rotation for the copper disc.
  3. Power source: Initially, a small amount of external force may be needed to start the rotation of the wheel. This can be provided manually, after which the rotation continues due to the induced current.
  4. Electric circuit: The copper disc is connected to an electrical circuit. When the disc rotates, it cuts across the magnetic field lines, inducing an electromotive force (emf) in the disc, which causes an electric current to flow through the circuit.
  5. Load: A resistor or other load can be connected to the circuit to demonstrate the generation of electricity and its ability to do work.
SKU: ACS16492CHEM0 Category:
  1. Electrical Safety: Ensure that all electrical connections are secure and insulated to prevent electric shocks. Use appropriate voltage levels and current limits for the experiment.
  2. Magnet Safety: Handle magnets carefully to avoid injuries or damage. Strong magnets can pinch fingers or attract metal objects forcefully.
  3. Mechanical Safety: Avoid placing fingers or other objects near moving parts of the apparatus during operation. Secure loose clothing and tie back long hair to prevent entanglement.
  4. Heat Dissipation: If the experiment involves significant electrical current, monitor the temperature of the copper disc to prevent overheating. Provide adequate ventilation or cooling if necessary.
  5. Stability: Ensure that the apparatus is stable and securely mounted to prevent it from tipping over during operation.
  6. Supervision: Conduct the experiment under the supervision of a knowledgeable instructor or researcher who can provide guidance on safe operation and troubleshooting.
  7. Emergency Procedures: Familiarize yourself with emergency procedures, including how to disconnect power quickly in case of malfunction or accident.
  8. Personal Protective Equipment (PPE): Depending on the specific experiment and potential hazards involved, consider wearing appropriate PPE such as safety goggles, gloves, and lab coats.
  9. Read Instructions: Before conducting the experiment, carefully read the manufacturer’s instructions and any safety guidelines provided.
