SPECIALTY AND FINE CHEMICALS

BLEACHING EARTH: THE ESSENTIAL PURIFICATION AGENT FOR OILS & FATS

Bleaching earth (activated clay) is a specially processed clay used to remove impurities from edible oils, mineral oils, and biofuels. With global consumption exceeding 2 million metric tons annually, this versatile adsorbent plays a critical role in producing clear, stable, and high-quality oils through its unique combination of physical and chemical adsorption properties.

Key Properties & Composition

Physical Characteristics

  • Appearance: Fine tan/gray powder
  • Particle Size: 10-100 μm (95% passing 200 mesh)
  • Bulk Density: 0.6-0.9 g/cm³
  • Surface Area: 100-300 m²/g
  • Oil Retention: 30-50% by weight

Chemical Composition

ComponentContent RangeFunction
Montmorillonite60-80%Primary active constituent
SiO₂50-70%Structural framework
Al₂O₃15-25%Acid activation sites
Fe₂O₃2-5%Color adsorption

Activation Process

1. Natural vs. Activated Bleaching Earth

TypeAcid ContentActivityBest For
NaturalNoneLowMild purification
Acid-Activated15-30% H₂SO₄HighChallenging oils

2. Activation Steps

  1. Mining: Select high-smectite clays
  2. Drying: Reduce moisture to <15%
  3. Acid Treatment: Sulfuric/hydrochloric acid (20-35%)
  4. Washing: Remove residual acid
  5. Drying/Milling: Optimize particle size

Major Industrial Applications

1. Edible Oil Refining (75% of use)

  • Impurity Removal:
    • Chlorophyll (90-98% reduction)
    • Peroxides (70-85% reduction)
    • Soaps (complete removal)
  • Dosage:
    • Palm oil: 0.5-2%
    • Soybean oil: 0.3-1.5%
  • Case Study: A Malaysian palm oil plant achieved 30% longer frying stability through optimized bleaching

2. Mineral Oil Processing

  • Lubricant Purification:
    • Removes asphaltenes
    • Improves color (200% lighter)
  • Wax Bleaching:
    • Food-grade paraffin production

3. Biodiesel Treatment

  • Soap Removal: 0.5-1.0% dosage
  • Phospholipid Adsorption: Critical for ASTM specs

4. Emerging Applications

  • Waste Oil Recycling:
    • Regenerator for used cooking oils
  • Water Treatment:
    • Heavy metal removal (Pb²⁺, Cd²⁺)

Performance Metrics

Adsorption Efficiency

ContaminantRemoval EfficiencyMechanism
Chlorophyll90-98%Chelation
Peroxides70-85%Catalytic decomposition
Phospholipids95-99%Polar adsorption
Trace Metals80-95%Ion exchange

Quality Parameters

TestSpecificationMethod
Moisture<12%ASTM D280
pH (10% slurry)2.5-7.0ISO 787-9
Filtration Rate<300 sec/100mLAOCS Cc 13e-92

Market Dynamics

Global Production

  • Leading Producers:
    • China (35%)
    • Clariant, Taiko Group, Musim Mas
  • Price Range:
    • $200-600/ton (2024)

Sustainability Trends

  • Regeneration:
    • Solvent extraction of spent earth
    • 3-5 reuse cycles possible
  • Low-Acid Activation:
    • Reducing wastewater load

Comparison to Alternatives

AdsorbentCostOil RetentionChlorophyll Removal
Bleaching Earth$30-50%Excellent
Activated Carbon$$$50-70%Good
Silica Gel$$$$20-30%Fair

Conclusion

Bleaching earth remains the most cost-effective solution for oil purification, combining superior adsorption capacity with low operational costs. As the food industry demands higher quality standards and sustainable practices, innovations in regeneration technologies and activation methods are extending its dominance in oil processing worldwide.
